Blackmagic Design esign Micro Converter Bi-Directional SDI to HDMI 12G
Blackmagic Design : Picture 1 thumbnail Blackmagic Design : Picture 2 thumbnail
Blackmagic Design

RENT Blackmagic Design Micro Converter Bi-Directional SDI to HDMI 12G

SKU: BMCVBDSH12GP

First Day ?
Daily
Price		 3-Day Wknd
Price		 Weekly
Price
$30 $30 $90
$30.00

Set your Rental Period to see your cost.

Your cost for

Replacement Value: $199.00 ?

We require insurance or a major credit card to hold the replacement value of the equipment you are renting

Not available for your selected rental period.

Call us at 212.627.8487 to discuss availability
Call to rent
customer service representative icon

Questions?

If you need assistance or have any questions at all, we’re ready to help.

customer service representative

Questions?

customer service representative icon

For more information on this item, questions about rates, special requests, or if you need any assistance, we’re here for you.

Call 212.627.8487

Email rent@adorama.com

Submit a Request Form

Details

RENT Blackmagic Design Micro Converter Bi-Directional SDI to HDMI 12G Features

Now you can convert in both directions simultaneously! Convert SDI to HDMI and HDMI to SDI in any combination of SD, HD or Ultra HD formats all at the same time! Micro Converter BiDirectional SDI/HDMI 12G lets you simultaneously convert SDI to HDMI and HDMI to SDI in all SD, HD and Ultra HD formats up to 2160p60! Each conversion direction can be a different SD, HD or Ultra HD video standard, it’s like getting two converters in one! With multi-rate 12G-SDI input and output connections, Micro Converter BiDirectional SDI/HDMI 12G is compatible with virtually all professional broadcast equipment, including level A and B devices.


It even automatically detects all SD, HD and Ultra HD formats! Micro Converter BiDirectional SDI/HDMI 12G has all you need to convert HDMI consumer gear to SDI. Use the input to convert HDMI computers or consumer cameras into 12G-SDI, while using the output for monitoring with big screen televisions or projectors! The all metal durable design is perfect for live production and broadcast. Plus it’s small enough to be hidden and used anywhere. It can be powered from any USB-C socket, or with the included power supply and international socket adapters!

Blackmagic Design Micro Converter Bi-Directional SDI to HDMI 12G Specifications

Inputs/OutputsJump to...

Video Inputs
1x BNC (12G-SDI) Female
1x HDMI (2.0) Female
Audio Inputs
No
Video Outputs
1x BNC (12G-SDI) Female
1x HDMI (2.0) Female
Audio Outputs
No
Other I/O
1x USB-C Firmware Input (Shared Power)
Expansion Slots
No

Format SupportJump to...

Input Video Format
SDI (8/10-Bit 4:2:2 RGB, YUV)
DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2KPsF at 25/29.97/30 fps
1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080PsF at 25/29.97/30 fps
1080i at 50/59.94/60 fps
Input Video Format (Contd.)
720p at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 59.94 fps
HDMI (8/10-Bit 4:2:2 RGB, YUV)
DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 line
Output Video Format
SDI (8/10-Bit 4:2:2 RGB, YUV)
DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2KPsF at 25/29.97/30 fps
1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080PsF at 25/29.97/30 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
Output Video Format (Contd.)
480i / 525 lines at 29.97 fps
576i / 625 lines at 25 fps
HDMI (8/10-Bit 4:2:2 RGB, YUV)
DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
UHD 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080p at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
576i / 625 lines at 50 fps
480i / 525 lines at 59.94 fps
Embedded Audio
HDMI/SDI

StandardsJump to...

Video Standard Compliance
SMPTE 259M/292M/296M/424M/425M-A/425M-B
HDCP Support
Yes, Version 2.2
HDMI CEC
Yes

HardwareJump to...

Tally Light
Yes
Wireless
No
OS Compatibility
macOS 10.15.15 or Later
Windows 11.1 or Later

PowerJump to...

Power I/O
1x USB-C (4.4 to 5.2 VDC ) Input
Power Consumption
Device: 5 W

EnvironmentalJump to...

Operating Temperature
32 to 72 Degree F (0 to 40 Degree C)
Storage Temperature
-4 to 140 Degree F (-20 to 60 Degree C)
Operating Humidity
0 to 90%

GeneralJump to...

Dimensions
3.18 x 2.32 x 0.98" (8.1 x 5.9 x 2.5cm)
Weight
6.13oz (174g)
