SmallHD allHD 1703 P3X Reference Grade 17
SmallHD : Picture 1 thumbnail SmallHD : Picture 2 thumbnail SmallHD : Picture 3 thumbnail SmallHD : Picture 4 thumbnail SmallHD : Picture 5 thumbnail SmallHD : Picture 6 thumbnail SmallHD : Picture 7 thumbnail SmallHD : Picture 8 thumbnail SmallHD : Picture 9 thumbnail SmallHD : Picture 10 thumbnail SmallHD : Picture 11 thumbnail SmallHD : Picture 12 thumbnail SmallHD : Picture 13 thumbnail SmallHD : Picture 14 thumbnail

RENT SmallHD 1703 P3X Reference Grade 17" Production Monitor with Bolt 500 TX Transmitter Kit

SKU: ~SM1703XSKR1

First Day ?
Daily
Price
3-Day Wknd
Price
Weekly
Price
$300 $300 $900
$300.00

Set your Rental Period to see your cost.

Your cost for

Replacement Value: $6,483.04 ?

We require insurance or a major credit card to hold the replacement value of the equipment you are renting

Not available for your selected rental period.

Call us at 212.627.8487 to discuss availability
Call to rent
customer service representative icon

Questions?

If you need assistance or have any questions at all, we’re ready to help.

This Kit Includes

  • SmallHD Reference Grade 17" Production Monitor with Teradek Sidekick II Receiver
  • SmallHD 17" Acrylic Basic Edition Screen Protector for 1703 Production Monitor
  • Anton Bauer Power Tap-20, 20" PowerTap to Female 4-pin XLR Cable
  • SmallHD 15V AC Power Adapter
  • Power Cable IEC 60320 110/250VAC
  • (2) x Belden 25' 3G-SDI Cable
  • SmallHD Sun Hood for 1700 Series 17" Production Monitors
  • (7) x Teradek Small Antenna
  • SmallHD Quick Release Hot Shoe RapidRail Mount for 1703, 2403, 3203 Monitors
  • SmallHD Anton Bauer Gold Mount Battery Bracket with XLR Cable and Cheese Plate for 1300, 1700 and 2400 Series Monitors
  • SanDisk 16GB ExtremePRO UHS-1 SDHC Memory Card
  • SmallHD C-Stand Mount and Table Stand Kit
  • InnerSpace SmallHD 17" Monitor Case
  • Teradek 18 Watt AC Adapter 6' Cable to 2-pin Lemo
  • (2) x Teradek 18" 2-Pin Lemo to PowerTap Adapter Cable
  • (2) x Belden 3' 3G-SDI BNC Cable
  • (2) x Teradek TX/RX 1/4-20" Thumb Screw
  • Teradek Bolt 500 XT 3G-SDI/HDMI Wireless Transmitter
customer service representative

Questions?

customer service representative icon

For more information on this item, questions about rates, special requests, or if you need any assistance, we’re here for you.

Call 212.627.8487

Email rent@adorama.com

Submit a Request Form

RENT SmallHD 1703 P3X Reference Grade 17" Production Monitor with Bolt 500 TX Transmitter Kit Features

The 13RX and 17RX production monitors provide cinematographers with an image they can trust. With high-performance display quality and the industry's most reliable real- time wireless technology built-in, these ruggedly designed production monitors bring tremendous value while eliminating the number of accessories on set.


Equipped with a reference grade, daylight viewable display, and built-in Teradek wireless receiver, smallHD 1703 P3X Bolt Sidekick is a 17-inch production monitor is a DIT's dream. It's literally a complete video village with a ruggedly built exterior. With color reproduction that rivals OLED technology and the ability to send real-time 3D LUTs downstream, the 17RX saves time, eliminates clutter and provides cinematographers with an accurate view of the post-production look.

SmallHD 1703 P3X Reference Grade 17" Production Monitor with Bolt 500 TX Kit Specifications


DisplayJump to...

Panel Type
IPS-Type LCD
Display Size
17" (43.2cm)
Resolution
1920 x 1080
Aspect Ratio
16:9
Viewing Angle
178 Degree Horizontal / 178 Degree Vertical
Brightness
1000 nits / cd/ sq. m
Contrast Ratio
1400:1
Color Depth
10-Bit (1.07 Billion Colors)
Pixel Density
133 ppi
Color Gamut
100% DCI-P3

Input/OutputJump to...

Video Inputs
2x BNC (3G-SDI)
Video Outputs
2 x BNC (3G-SDI), 1 x HDMI Type A
Embedded Audio
SDI: 8-Channel
Audio Output
1x 1/8" / 3.5 mm Headphone Jack
Built-In Speaker
Stereo
Power I/O
1x XLR 4-Pin Input, 1x LEMO 2-Pin (2 A) Output
USB Ports
3x USB-A 2.0
Card Slot
1x SD

Format SupportJump to...

Video Formats
SDI (10-Bit 4:2:2 YCC)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080PsF: 30/29.97/25/24/23.98
1080i: 120/119.88/100/60/59.94/50
720p: 60/59.94/50/30/29.97/25/24/23.98
576i: 50 / 480i: 59.94
Signal Conversion
SDI to HDMI

PowerJump to...

AC Input
100 to 240 VAC, 50 / 60 Hz
DC Input
12 to 34 VDC
Battery
Not Included
Power Consumption
20 W (Idle), 104 W (Max)

MountingJump to...

Mount Options
6 x 1/4"-20 Female, 6 x 3/8"-16 Female

EnvironmentalJump to...

Certifications
CE, FCC, IC, RoHS
Operating Temp.
32 to 100 Degree F (0 to 37 Degree C)
Storage Temp.
0 to 104 Degree F (-17 to 40 Degree C)

GeneralJump to...

Dimensions
17 x 11.7 x 2.5" (43.2 x 29.7 x 6.3cm)
Weight
12.26 lbs (5.56kg)
